Настройка виртуальной машины ISP

• Базовая настройка:
  • имя
  • адресация
  • forwarding

hostnamectl set-hostname ISP; exec bash
sed -i "s/HOSTNAME=localhost/HOSTNAME=ISP/g" /etc/sysconfig/network

mkdir /etc/net/ifaces/ens2{0,1,2,9}
echo "TYPE=eth" > /etc/net/ifaces/ens20/options
cp /etc/net/ifaces/ens2{0,1}/options
cp /etc/net/ifaces/ens2{0,2}/options
cp /etc/net/ifaces/ens2{0,9}/options

mkdir /etc/net/ifaces/lo{1,2}
echo "TYPE=dummy" > /etc/net/ifaces/lo1/options
cp /etc/net/ifaces/lo{1,2}/options

echo "63.27.19.254/23" > /etc/net/ifaces/ens20/ipv4address
echo "84.212.78.94/27" > /etc/net/ifaces/ens21/ipv4address
echo "34.95.33.254/24" > /etc/net/ifaces/ens22/ipv4address
echo "34.35.36.62/26" > /etc/net/ifaces/ens29/ipv4address
echo "192.168.255.1/32" > /etc/net/ifaces/lo1/ipv4address
echo "100.64.1.1/16" > /etc/net/ifaces/lo2/ipv4address

sed -i "s/net.ipv4.ip_forward = 0/net.ipv4.ip_forward = 1/g" /etc/net/sysctl.conf
systemctl restart network

• Проверка:

[root@ISP ~]# ip -c -br -4 a
lo               UNKNOWN        127.0.0.1/8
ens19            UP             172.20.20.172/24
ens20            UP             63.27.19.254/23
ens21            UP             84.212.78.94/27
ens22            UP             34.95.33.254/24
ens29            UP             34.35.36.62/26
lo1              UNKNOWN        192.168.255.1/32
lo2              UNKNOWN        100.64.1.1/16
[root@ISP ~]# sysctl net.ipv4.ip_forward
net.ipv4.ip_forward = 1
[root@ISP ~]#

•  Устанавливаем пакет frr и iptables:

apt-get update && apt-get install -y iptables frr

• Настраивает iptables для доступа в сеть Интернет из сетей FW-HQ, RTR-BR и OUT-CLI:

iptables -t nat -A POSTROUTING -s 63.27.18.0/23 -o ens19 -j MASQUERADE
iptables -t nat -A POSTROUTING -s 84.212.78.64/27 -o ens19 -j MASQUERADE
iptables -t nat -A POSTROUTING -s 34.95.33.0/24 -o ens19 -j MASQUERADE
iptables -t nat -A POSTROUTING -s 34.35.36.0/26 -o ens19 -j MASQUERADE
iptables-save >> /etc/sysconfig/iptables
systemctl enable --now iptables

•  Проверка:

[root@ISP ~]# iptables -t nat -L -n -v
Chain PREROUTING (policy ACCEPT 0 packets, 0 bytes)
 pkts bytes target     prot opt in     out     source               destination

Chain INPUT (policy ACCEPT 0 packets, 0 bytes)
 pkts bytes target     prot opt in     out     source               destination

Chain OUTPUT (policy ACCEPT 3 packets, 228 bytes)
 pkts bytes target     prot opt in     out     source               destination

Chain POSTROUTING (policy ACCEPT 3 packets, 228 bytes)
 pkts bytes target     prot opt in     out     source               destination
    0     0 MASQUERADE  0    --  *      ens19   63.27.18.0/23        0.0.0.0/0
    0     0 MASQUERADE  0    --  *      ens19   84.212.78.64/27      0.0.0.0/0
    0     0 MASQUERADE  0    --  *      ens19   34.95.33.0/24        0.0.0.0/0
    0     0 MASQUERADE  0    --  *      ens19   34.35.36.0/26        0.0.0.0/0
[root@ISP ~]#

•  Настройка BGP и IS-IS:

sed -i "s/bgpd=no/bgpd=yes/g" /etc/frr/daemons
sed -i "s/isisd=no/isisd=yes/g" /etc/frr/daemons
systemctl enable --now frr
vtysh

conf t
router isis 0
is-type level-2-only
net 49.0001.1921.6825.5001.00
exit
interface lo1
ip route isis 0
exit
interface ens21
ip route isis 0
isis circuit-type level-2-only
isis network point-to-point
exit
router bgp 64499
bgp router-id 192.168.255.1
no bgp ebgp-requires-policy
neighbor 192.168.255.2 remote-as 64499
neighbor 192.168.255.2 description iBGP-to-RTR-BR
neighbor 192.168.255.2 update-source lo1
neighbor 34.95.33.33 remote-as 64499
address-family ipv4 unicast
network 0.0.0.0/0
network 100.64.0.0/16
neighbor 192.168.255.2 next-hop-self
neighbor 192.168.255.2 default-originate
neighbor 192.168.255.2 soft-reconfiguration inbound
neighbor 34.95.33.33 default-originate
exit-address-family
end
wr mem

• Проверка:

ISP# show running-config
Building configuration...

Current configuration:
!
frr version 10.2.2
frr defaults traditional
hostname ISP
log file /var/log/frr/frr.log
no ipv6 forwarding
!
interface ens21
 ip router isis 0
 isis circuit-type level-2-only
 isis network point-to-point
exit
!
interface lo1
 ip router isis 0
exit
!
router bgp 64499
 bgp router-id 192.168.255.1
 no bgp ebgp-requires-policy
 neighbor 34.95.33.33 remote-as 64499
 neighbor 192.168.255.2 remote-as 64499
 neighbor 192.168.255.2 description iBGP-to-RTR-BR
 neighbor 192.168.255.2 update-source lo1
 !
 address-family ipv4 unicast
  network 0.0.0.0/0
  network 100.64.0.0/16
  neighbor 34.95.33.33 default-originate
  neighbor 192.168.255.2 next-hop-self
  neighbor 192.168.255.2 default-originate
  neighbor 192.168.255.2 soft-reconfiguration inbound
 exit-address-family
exit
!
router isis 0
 is-type level-2-only
 net 49.0001.1921.6825.5001.00
exit
!
end
ISP#
